Reducer Elbow 90 (SCH 80)

Reducer elbows are used within the plumbing system to direct cold water supply through uPVC pipes of varying diameters. The primary function of reducer fittings like the reducer elbow is to regulate the flow of water by phasing water flow from a larger to a smaller pipe.



SIZE ID-1 OD-1 WT-1 SL-1 ID-2 OD-2 WT-2 SL-2 L H
3⁄4 x 1⁄2” 26.97 34.79 3.91 25.4 21.64 29.1 3.73 22.23 57 54
1 x 1⁄2” 33.78 42.88 4.55 28.58 21.64 29.1 3.73 22.23 65 64
1 x 3⁄4” 33.78 42.88 4.55 28.58 34.79 3.91 25.4 68 66
Advantages
  • - Constitutes the corner fitting of residential plumbing systems
